Segmented Amorphous Stator Laminations
- Ultra-Low Core Loss: ≤ 0.2 W/kg at 1.5 T, 50 Hz—70% lower than silicon steel.
- Segmented Core Design: Reduces stress and deformation during assembly or high-speed operation.
- Custom Geometry: Segments can be optimized for different stator diameters or pole configurations.
- Superior Thermal Performance: Amorphous alloys dissipate heat efficiently and resist localized hotspots.
- Lightweight Construction: Up to 25% lower density compared to electrical steel laminations.
Technical Specifications
| Parameter | Specification |
| Material | Amorphous Alloy (Fe-based / Co-based) |
| Magnetic Flux Density | ≤ 1.56 T |
| Lamination Thickness | 0.02 – 0.05 mm |
| Segment Type | Arc / Petal / Modular Geometry |
| Core Loss | ≤ 0.2 W/kg @ 1.5 T, 50 Hz |
| Permeability | ≥ 10,000 μ |
| Operating Frequency | 50 Hz – 20 kHz |
| Stack Height | 10 – 400 mm |
| Coating | Heat-resistant Epoxy or Inorganic Oxide |
| Applications | EV Traction / Servo / Aerospace / High-speed Drives |
Customization & OEM Service
- Define number and shape of core segments.
- Choose Fe-based or Co-based amorphous alloy type.
- Specify thickness for frequency and power density balance.
- Design segment-to-slot fit for unique stator topologies.
- Provide prototype to mass-production support with PPAP documentation.
- Offer surface coating or bonding method customization.
- Include export packaging and OEM marking options.
Application Fields
- Electric vehicle traction motors
- Servo and industrial automation motors
- Aerospace power systems and UAV drives
- High-speed compressors and turbines
- Magnetic levitation and precision motion systems
